Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J

时间:2025-07-08人气:作者: 小编

Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J

Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J

Smart Swing Arm Barriers

Smart swing barrier turnstile

Fully Automatic Swing Arm Barriers

Place of Origin:



shenzhen

Brand Name:



cxt

Certification:



Single label product appearance patent

Model Number:



CXT-PY510J

Chat NowSmart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510JSmart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510JSmart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510JSmart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510JSmart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510JSmart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510JProduct DetailsChassis Material:National Standard (No. 304) Stainless Steel, Thickness 1.2-1.5mmChassis Size (standard):1400 Length * 300 Width * 1000 Height (MM)Processing Technology:Bending, Cutting, Welding, Polishing, Grinding And Other ProcessesChannel Net Width:500-550mmDoor Wing Height:≤1800mmDoor Wing Material:High-quality Acrylic (thickness 12-18mm) Or Tempered Glass (thickness ≤12mm)Highlight:

Smart Swing Arm Barriers

Smart swing barrier turnstile

Fully Automatic Swing Arm Barriers

Payment & Shipping TermsMinimum Order Quantity1Price90~3500USDPackaging DetailsCartons and wooden boxesDelivery Time20 working daysPayment TermsPublic AccountSupply Ability500psRELATED PRODUCTSGood price Intelligent Access Control Turnstile Gate RFID Automatic Anti Collision 510YX onlineVideo

Intelligent Access Control Turnstile Gate RFID Automatic Anti Collision 510YX

Get Best PriceGood price Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J onlineVideo

Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J

Get Best PriceGood price Global best-selling anti-climbing and anti-drilling fully automatic 1.8m face recognition brushless motor sliding gate 510Z onlineVideo

Global best-selling anti-climbing and anti-drilling fully automatic 1.8m face recognition brushless motor sliding gate 510Z

Get Best PriceGood price High Security Glass Swing Turnstile Access Control Multifunctional 510H onlineVideo

High Security Glass Swing Turnstile Access Control Multifunctional 510H

Get Best PriceCONTACT USChat NowProduct Description

AI smart app ticket checking attractions brushless motor fully automatic Glass Sliding Turnstile CXT-PY510J

Sliding gate CXT-PY510J

ModelCXT-PY510J
Specifications1400*300*1000mm
Pole length250mm
ProcessProduced by bending, cutting, welding, polishing, grinding and other processes
MaterialNational standard 304 stainless steel (201 stainless steel, iron paint can be customized)

Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J 0


Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J 1


Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J 2

Intelligent sliding gate (full-height wing gate) is a high-tech product mainly used for intelligent management of personnel channels. Compared with ordinary wing gates, it has the effect of anti-climbing and anti-drilling, and is of higher grade. This product adopts industrial-grade circuit control system and humanized scientific mechanical transmission design. This product has stable performance, complete functions, humanized design and high grade. It is mainly used in high-end and crowded places such as subways, docks, clubs, smart buildings, villa communities, hotel lobbies, etc.

The device is compatible with various access control and identification system equipment. Induction card access control, biometric access control, electrostatic testing, etc. can realize intelligent channel control and management through simple docking with the sliding gate.

Functions and features of intelligent sliding gate:

1) It has fault self-detection and logic judgment functions, which is convenient for users to maintain and debug functions;

2) Flexible dial code setting of various performances of the equipment, up to dozens of types;

3) Intelligent anti-pinch function, when there is a person or obstacle at the reset position of the barrier arm, it will automatically stop or rebound and send out an alarm signal;
4) Multiple mode alarm function, including illegal intrusion, anti-intrusion, tailgating, and passage timeout alarms;
5) Anti-collision function, when no gate opening signal is received, the barrier arm will automatically lock;
6) Reverse intrusion closing alarm function, when someone enters from the reverse direction after swiping the card forward, the barrier wing will quickly close and send out an alarm;
7) Flexible passage indication function, high-brightness indicator light plus its humanized prompt function, making the channel more distinctive;
8) Normally open and normally closed modes are adjustable, and can be easily controlled by dialing or external manual buttons;
9) Automatic detection and reset function, after opening the gate, if no object is detected within the specified time (adjustable), the system will automatically cancel the passage authority;
10) Automatic normally open when power is off to meet fire protection requirements;
11) It can be connected with a variety of control devices and receive relay switch signals to work;
12) Various traffic modes, can control personnel entry and exit in one direction or two directions, or be controlled in one direction and freely pass in the opposite direction;
13) Strong ability to adapt to the environment, can work normally in various harsh environments, super strong self-protection ability, can adapt to weak current short circuit, strong light exposure, fog, rain, snow, typhoon weather and environmental changes.

Main structure and configuration of intelligent sliding gate (single channel)
2 standard stainless steel chassis, 2 plexiglass arms, 2 industrial-grade main control boards, 2 transformers, 2 motors, 2 sets of movement and transmission parts, 4-6 pairs of infrared beams, 4 high-brightness warning lights

Standard technical parameters of intelligent sliding gate
◇ Chassis material: National standard (No. 304) stainless steel, thickness 1.2-1.5mm
◇ Chassis size (standard): 1400 length * 300 width * 1000 height (MM)
◇ Processing technology: produced by bending, cutting, welding, polishing, grinding and other processes
◇ Channel net width: 500-550mm
◇ Door wing height: ≤1800mm
◇ Door wing material: high-quality acrylic (thickness 12-18mm) or tempered glass (thickness ≤12mm)
◇ Weight: about 70Kg
◇ Entry and exit direction: unidirectional or bidirectional
◇ Working voltage: AC220 ±10 V/50 HZ
◇Drive motor: DC motor (24V)
◇Input interface: Dry contact signal
◇Passing speed: about 30 people/minute
◇Gate opening and closing time: 0.5-2 seconds adjustable
◇Time required to enter the passing state after power-on: 3 seconds
◇Working environment: indoors, outdoors (it is recommended to build a shed)
◇Temperature: (industrial standard) -40℃——80℃
◇Relative humidity: ≤95%, no condensation

The intelligent sliding gate also has expandable functions:

1) Bidirectional automatic counting function, which can "add" in the forward direction and "subtract" in the reverse direction, and automatically count the number of people present (customized).

2) Voice prompt function: "Welcome! Bon voyage! Please swipe your card!" etc. (customized);

3) Telescopic arm material and primary color selection.

Widened flap barrier gate is a specially designed turnstile gate that increases the width of the gate passage to accommodate a wider flow of people.

Channel width increase: Compared to ordinary wing gates, widened wing gates can have a channel width of up to 550mm-900mm, or even wider, to meet the needs of people carrying large luggage or special equipment.
Strong adaptability: Suitable for places such as airports, train stations, subway stations, hospitals, schools, scenic spots, etc. that need to handle a large number of people and logistics.
High safety: Advanced anti pinch technology and safety sensors are used to ensure that there is no harm to the human body or objects during the passage process.
High degree of intelligence: It can integrate multiple recognition methods such as facial recognition, fingerprint recognition, and QR code recognition to achieve fast passage and identity verification.

Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J 3

Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J 4


Smart Swing Arm Barriers Fully Automatic 304 Stainless Steel 510J 5
